HiPath HG 1500 boards
Installation For internal use only
A31003-K5020-S100-6-7620
2-10 Service Manual
lan2de.c02
Table 2-9 Assignment of the CHAMP-RJ45 LAN adapter cable
CHAMP con-
nector
RJ45 socket Signal Ethernet
34 1 TDP LAN #2
35 2 TDN
36 4 TT1
37 5 TT2
38 3 RDP
39 6 RDN
40 7 RT1
41 8 RT2
42 1 TDP LAN #1
43 2 TDN
44 4 TT1
45 5 TT2
46 3 RDP
47 6 RDN
48 7 RT1
49 8 RT2
25, 50 Housing Shield
Table 2-10 HXGM LED concept
H1 - red H2 - green Meaning
Flashing Off Board is included in Firmware, no valid SW on board,
therefore V.24 charge mode
On Off Board is included in Firmware, e.g. following reset, re-
boot
On -> Off Off Board at SW start, reboot
Off Off -> On Board in idle status following reboot (call number of
logon router)
Off On At least one B channel occupied
On On Approx. 20 s long: Board ready to activate reset (e.g. fol-
lowing APS transfer or a FATAL error), waiting for Hicom
reset
