HiPath HG 1500 board
s
lan2de.c02
A31003-K5020-S100-6-7620
Service Manual
2-1
For internal use only Installation
2 Installation
2.1 HiPath HG 1500 boards
HG 1500 supports two function groups: the “voice functionality” with the features
H.323 GW and TFA and the “data functionality” with the features VCAPI and RAS. A
board variant (X100) that only supports the data functionality (Data only) is available;
this board is not equipped with signal processors and the associated logic.
2.1.1 HXGS
Introduction
The HiPath HG 1500 board HXGS connects Hicom 150 E Office/Hicom 150 H Office-
Com/OfficePoint with the LAN environment. The board supports up to 16 B channels.
The following board variants are available:
HiPath HG 1500 HXGS Voice and Data (S30810-Q2931-X)
HiPath HG 1500 HXGS Data only (S30810-Q2931-X100)
HiPath HG 1500 HXGS2 Voice and Data 2nd LAN interface (S30810-Q2939-X000)
HiPath HG 1500 HXGS2 Data only 2nd LAN interface (S30810-Q2939-X100)
Board slot
Table 2-1 HXGS application option/slot
Possible application Boards Slot
OfficePoint
Hicom 150 E as of V 2.2
P30370-P722-A680-*
Hicom 150 H as of V 1.0
P30370-P802-A680-*
Hicom 150 H as of V 1.2
P30370-P822-A680-*
1 All slots
OfficeCom
Old HW
CBFC
Hicom 150 E as of V 2.2
P30370-P723-A680-G1
2 * Slots 4 and 5 only
OfficeCom
New HW
CBPC
Hicom 150 E as of V 2.2
P30370-P721-A680-*
Hicom 150 H as of V 1.0
P30370-P801-A680-*
Hicom 150 H as of V 1.2
P30370-P821-A680-*
2 * All slots
