Building Technologies Basic Documentation LMV5... CC1P7550en
7 Boiler controller / load controller 22.05.2018
Stage 1 Stage 2 Stage 3
I (mA) 5 10 15
U (V) 2.5 5 7.5
The detection of short-circuits and line interruptions is ensured – similar to the sensor
inputs.
In operating mode 2 (intLC), changeover between the 2 internally defined setpoints W1
and W2 can be implemented by means of an external (potential-free) contact.
The settings described under Input 3 can also be made from a BACS connected to the
AZL5 via RS-232 and bus interface.
An external predefined setpoint exists with Int LC bus.
An external predefined load exists with Ext LC bus.
Parameter LC_OptgMode (intLC o.DDC / extLC o.DDC)
External predefined load,
multistage
External setpoint
changeover
External setpoints or
predefined load via
digital interface
