Building Technologies Basic Documentation LMV5... CC1P7550en

21 Dimensions 22.05.2018

21 Dimensions

Dimensions in mm

19 36

41,5 41,5

222

240

9 142

160

7550m03/0703

Figure 127: Dimension PLL52

PLL52
