153/327
Building Technologies Basic Documentation LMV5... CC1P7550en
8 Display and operating unit AZL5 22.05.2018
- Continue by pressing Enter
⇒
A c t u a t o r §
P o s i t i o n s
F o l l o w e d
N o t f o l l o w e d
This selection can be used to determine whether the load and the positions of the
selected curvepoint shall be approached. Hence, curvepoints can be changed without
having to drive to them.
The following description also applies to without driving, but the load and the positions
will not be approached:
Caution!
Curvepoints that have been changed via the without driving function must be
checked to ensure that their combustion values are correct!
If curvepoints have been set without driving, the degree of readjustment is based on
estimation. This means that there is no proof yet that all curvepoints are correctly set
from the combustion point of view. This must be ensured using adequate measuring
equipment.
- Continue by pressing Enter
⇒
P o i n t | L o a d : 2 3 . 5
: 3 | F u e l : 2 3 . 2
O 2 | A i r : 4 1 . 6
4 . 5 | A u x : 3 3 . 3
It is to be noted that with these settings, which can be made in standby and normal
operation, the actuators are driven to the displayed or changed positions.
Traveling to the load that is assigned to the curvepoint can be stopped by pressing Esc.
During the time the actuators approach the positions, the display shows «>» in place of
«:».
Β
Note!
If a new point is created, the current actual values are adopted as point data and can
be changed.
The parameter that shall be changed (e.g. Fuel position) can be selected by changing
the pointer position.
P o i n t | L o a d : 2 3 . 5
: 3 | F u e l : 2 3 . 2
O 2 | A i r : 4 1 . 6
4 . 5 | A u x : 3 3 . 3
