Canceling a curvepoint
When accessing this menu, the pointer is positioned on Point. To cancel a curvepoint,
the pointer must be positioned on Point.
- Pointer positioned on Point:
P o i n t | L o a d : 2 3 . 5
| F u e l : 2 3 . 2
M a n | A i r : 4 1 . 6
| A u x : 3 3 . 3
- Continue by pressing Enter
⇒
P o i n t | L o a d : 2 3 . 5
: 3 | F u e l : 2 3 . 2
O 2 | A i r : 4 1 . 6
4 . 5 | A u x : 3 3 . 3
The respective point (SP) is selected by calling up the curvepoint number.
The data associated with the point number are always displayed in the column on the
right (see above).
- For canceling the parameter data:
Select the required curvepoint, then continue by pressing Enter
⇒
P o i n t | P o i n t
: 3 | c h a n g e ?
M a n | d e l e t e ?
|
Here, the pointer position can vary between change? and delete?.
To cancel the curvepoint, select delete?
Confirm by pressing Enter.
The selected point has been canceled and the actuators travel to the positions
determined by the remaining curvepoints, in other words, the system’s output is
maintained.
Point of curve number
