160/327
Building Technologies Basic Documentation LMV5... CC1P7550en
8 Display and operating unit AZL5 22.05.2018
Now, the value can be changed and the respective actuator follows at the rate of the set
ramp speed.
Enter saves the value, Esc discards it.
This way, all stages can be set, one by one.
The following table shows the response of the system when a point is selected.
However, the relevant valve is switched on only when at least the switch-on point is
definitely used (÷ XXXX).
Selected point Response Remark
Operating point stage 1 Approach of stage 1 Fine adjustment of stage 1
Switch-on point stage 2 Approach of stage 1 Adjustment of stage 1 off
Switch-off point stage 2 -- Adjustment of stages 1 and 2 off
Operating point stage 2 Approach of stage 2 Fine adjustment of stage 2
Switch-on point stage 3 Approach of stage 2 Adjustment of stage 2 off
Switch-off point stage 3 -- Adjustment of stages 2 and 3 off
Operating point stage 3 Approach of stage 3 Fine adjustment of stage 3
System response when a point is selected
