175/327
Building Technologies Basic Documentation LMV5... CC1P7550en
9 Commissioning instructions for the LMV5 22.05.2018
To create a new curvepoint, select Manual. Set the output of the new point and
acknowledge by pressing Enter.
During the manual action, the actuators travel on the interpolated straight lines between
the curvepoints.
After pressing Enter, each individual actuating device can be selected to optimize the
position.
To leave the curvepoint setting, press the Esc button or store the point by pressing
Enter.
Finally, you can limit the burner output to a minimum and maximum in accordance with
the boiler’s requirements.
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
RatioControl
GasSettings
LoadLimits
MinLoadGas
MaxLoadGas
Select Autom/Manual/Off and then Burner off.
Menu level 1
Menu level 2
Menu level 3 Menu level 4 Menu level 5 Menu level 6
ManualOperation
Autom/Manual/Off
Creating a new curvepoint
16. Load limits
17. Shutdown
