Siemens LMV50 series

179/327
Building Technologies Basic Documentation LMV5... CC1P7550en
9 Commissioning instructions for the LMV5 22.05.2018
The burner operates at ignition load or with the first burner stage. The positions of the
actuators can now be changed.
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
RatioControl
OilSettings
CurveParams
Curve Settings
*) Actuator
Positions
followed
not followed
*) Not a parameter name, but a term of curve parameterization
It is recommended to use the function Actuator positions followed to set all switching
points and operating points.
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
RatioControl
OilSettings
CurveParams
Curve Settings
*) Actuator
Positions
followed
not followed
————————
Curve Settings
(curve setting stage:
Stage 1...3 and on
and off switching
points)
*) Not a parameter name, but a term of curve parameterization
25. Setting the burner
stages
