2.3 Hardware and software components
2.3.1 Validity
This Application is valid for:
• LOGO! 0BA7
• SINAMICS V20
• STEP 7 as of V12
• S7-1200
2.3.2 Components used
Note
The cooling water system is designed for a 0.12 kW motor with a corresponding
SINAMICS V20 frequency converter.
Hardware components
Table 2-1
No.
Component
No.
Article number
Note
1
LOGO! Power 24V/1.3A
1
6EP3331-6SB00-0AY0
2
LOGO! 12/24RCE
1
6ED1052-1MD00-0BA7
DC
3
LOGO! AM2 AQ
1
6ED1055-1MM00-0BA0
0-10V; optional *
4
LOGO! TD
1
6ED1055-4MH00-0BA0
incl. cable
5
Analog monitoring relay
1
3UG3501-1AL20
6
Wire electrode for level
monitoring
1
3UG3207-3A
three-pole
7
SINAMICS V20 frequency
converter
1
6SL3210-5BE13-7CV0
optional *
8
Motor
1
1LA7060-4AB10
optional *
* simulation possible even without these components
Accessories
Table 2-2
No.
Component
No.
Article number
Note
1
Miniature circuit breaker
1
5SX2116-6
1 pole B, 16A
2
NH fuse cartridge
3
3NA3810 + 3NH3030
25A + base
3
Passage terminal, beige
*
8WA1011-1DF11
Ø 2.5 mm², up
to 24A, >800V
4
PE passage terminal
*
8WA1011-1PF00
Ø 2.5 mm²
5
Jumper
*
8WA1822-7VF01
6
Standard mounting rail 35mm
1
6ES5 710-8MA11
483 mm
* as needed
