9Getting started
VAR Language: English; VAR issue date: 16-Juli-2003
Insert SIM card/battery
The service provider supplies you
with a SIM card on which all the im-
portant data for your line is stored.
If the SIM card has been delivered
in credit-card size, snap the smaller
segment out and remove any rough
edges.
Press grooved area
1, then remove
the cover forwards/upwards in the
direction of the arrow
2.
• Place the SIM card into the slot
with the contact surface facing
downwards. Gently push the holder
tab over the SIM card
3 (ensure
the bevelled corner is correctly po-
sitioned).
• Insert the battery sideways into
the phone
4, then press down-
wards
5 until it engages.
• To remove, press the retaining tab
on the side of the battery, then lift
the battery out.
• Place cover on phone
6 and then
push to the lower edge
7, until it
clicks into place.
1
2
3
Additional information
Please switch off your phone before
removing the battery!
Only 3V SIM cards are supported. Please
contact your service provider if you have an
older card.
SIM card problems ............................p. 92
5
4
7
6
