Operator control and display elements
3
3.1 Front side
Overview
① Emergency stop button
② Operating modes, machine functions
③ User keys T1 to T15
④ Direction keys with rapid traverse override (R1 to R15)
⑤ Spindle control
⑥ Override switch for the spindle control
⑦ Feed control
⑧ Override switch for the feed control
⑨ Slots for two control devices (d = 16 mm or 22 mm)
⑩ Reset key
⑪ Keyswitch (four positions)
Figure 3-1 Position of the operator controls on the MCP 398C
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 25
