Spare parts/accessories
10
10.1 Overview
Name Description Article number
EM 66 Expansion module (66 mm wide) 6FC5303-0AF30-0AA0
EM 131 Expansion module (131 mm wide) 6FC5303-0AF31-0AA0
Emergency stop but‐
ton
22 mm actuating element, 40 mm mushroom
pushbutton, snap action with tamper protection,
latching, red, with holder, non-illuminated
3SB3000-1HA20 *)
Contact block with 2 contacts, 1 NO + 1 NC, 2-
pole ,screw terminal
3SB3400-0A *)
Keyswitch Keyswitch with key 6FC5247-0AF02-0AA0
Key Ten key sets, each with three keys for the key‐
switch settings 1, 2, 3
6FC5148-0AA03-0AA0
Tension jacks Tension jack set (9 items) for supplementary op‐
erator components with 2.5 mm profile, length:
20 mm
6FC5248-0AF14-0AA0
Override
spindle / rapid tra‐
verse
Electronic rotary switch 1x16G, T=24, cap, but‐
ton, pointer, spindle dials and rapid traverse
6FC5247-0AF12-1AA0
Override
feed / rapid traverse
Electronic rotary switch 1x23G, T=32, cap, but‐
ton, pointer, feed and rapid-traverse dials
6FC5247-0AF13-1AA0
Rapid traverse dial 1 set with 20 units for MCP 398C 16-position ro‐
tary switch
6FC5248-0AF30-0AA0
Key caps Square, can be labeled with laser,
1 set of 90, ergo-gray and 20 each of red/green/
yellow/medium gray
6FC5248-0AF12-0AA0
Square, for insert labels,
1 set of 90, clear
6FC5248-0AF21-0AA0
Square, can be labeled with laser, 1 set with 500,
ergo-gray (light basic)
6FC5348-0AF00-0AA0
Square, can be labeled with laser, 1 set with 500,
mid-gray (medium basic)
6FC5348-0AF01-0AA0
Signal cable, hand‐
wheel
Connection cable for the handwheel, max.
length: 5 m
xy is the length code:
x (m) = A (0) ...F (5); y (dm) = 0 ... 8
For details, see Handwheel connection
(Page 60).
6FX8002-2CP00-1Axy
Cables Cable set with 60 pieces for additional control
devices of the machine control panels
Length: 500 mm
6FC5247-0AA35-0AA0
*) Safety-related
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 59
