3.2 Rear side
①Feed override
②Spindle override
③Additional override switch
④Power supply interface
⑤Handwheel connection
⑥Customer-specific inputs
⑦Switch S1
⑧Switch S2
⑨Handwheel connection
⑩Ethernet 1
⑪EMERGENCY STOP
⑫Protective conductor connection
⑬Ethernet 2
⑭Customer-specific outputs
Figure 3-3 Rear of the MCP 398C
Operator control and display elements
3.2 Rear side
Machine control panel: MCP 398C
28 Manual, 12/2017, A5E43199783B AA
