LEDs
H500 - POWER OK (green)
H501 - BUSFAULT (red)
H502 - BUSSYNC (green)
H505: TEMP ALARM (red)
Figure 3-4 MCP 398C - LEDs
Operator control and display elements
3.2 Rear side
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 29
