Dimension drawing
① Mounting panel
② Sealing area
③ Pressure points for tension jacks
Figure 5-2 Mounting cut-out with tension jack positions
Table 5-1 Mounting cut-out
Device Width (mm) Height (mm) Overall depth +
ventilation clear‐
ance (mm)
MCP 398C 379.5 + 1 206.5 + 1 63 + 10
EM 66 47.5 + 1 206.5 + 1 63 + 10*
EM 131 112.5 + 1 206.5 + 1 63 + 10*
*) Depends on the installed components:
Tension jacks
The machine control panel is attached using eight tension jacks (tightening torque, 0.5 Nm).
Mounting position
Max. 45° to the vertical For mounting positions greater than 45°, a fan must also be installed
to keep the ambient temperature of the machine control panel constantly below 55° C.
Mounting
5.2 Mounting
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 35
