2.4
User interface
2.4.1
Screen layout
Overview
1
Active operating area and mode
2
Alarm/message line
3
Channel operational messages
4
Display for
●
Active tool T
●
Current feedrate F
●
Active spindle with current status (S)
●
Spindle utilization rate in percent
●
Name of the active tool holder with display of a rotation in space and plane
●
Name of the active kinematic transformation
5
Vertical softkey bar
Introduction
2.4 User interface
Milling
40
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
39
41
