2. Output of the IP address
While the SW version output is activated, the current IP address of the MCP can be output by
pressing the "SPINDLE START" key. The 4-digit IP address is output in succession. The
advance is performed with the "SPINDLE START" key.
① Hundreds position of the bus address
② Tens position of the bus address
③ Ones position of the bus address
④ "FEED Start", "FEED STOP" and "SPINDLE START" keys
Figure 8-3 Activating the IP address output
Example: IP address 192.168.214.10
1.
2.
Diagnostics
8.2 Output functions
Machine control panel: MCP 398C
48 Manual, 12/2017, A5E43199783B AA
