Mounting / Installation
Base attachment wet BA721
40
Building Technologies A6V10316298_e_en_--
Fire Safety 2014-05-21
Fig. 1 Installation of base attachment wet BA721
l Installation on back box on substructure (2 screws)
l Installation of housing cover on back box (4 screws)
l Installation of detector base (2 screws)
Fig. 2 Master gauge for recesses
Fig. 3 Installation of protective cage DBZ1194, M20 x 1.5 metal cable gland, designation plate
DBZ1193A
Fig. 4 Installation of EMC-protective cage FDBZ294
WARNING
Danger of injury
● When installing, use a secured ladder or work platform.
Only use detector exchanger DX791 as an installation to
Installation (Fig. 1 and Fig. 2)
1. Install the M20 x 1.5 metal cable gland(s) in the back box of the base
attachment wet.
2. Fit the back box securely to the substructure with 2 screws (detail A).
3. Screw the housing cover to the back box with the 4 screws.
4. Push the detector base into base attachment wet BA721.
a You must be able to hear the detector base click into place.
5. Screw the detector base securely onto base attachment wet BA721 using
2 screws.
Removing the detector base
1. Loosen the two screws on the detector base.
2. Disengage the lock with a screwdriver ('click').
3. Remove the detector base from base attachment wet BA721.
