Mounting / Installation
5
41
Building Technologies A6V10316298_e_en_--
Fire Safety 2014-05-21
5.6 Detector locking device LP720
The point detector can be protected against theft with the detector locking device
LP720.
The detector locking device LP720 is compatible with
l Detector base (collective) DB110
l Detector base (collective) DB110D
l Detector base (collective) DB110R
l Detector base (collective) DB110 RD
1.
2.
A
B
A Grub screw M3 x 12 mm B Hexagonal wrench
1. Insert the detector in the detector base.
2. Insert the hexagonal wrench provided in the bore hole on the detector housing
and tighten the grub screw.
