Product Characteristics
4.1 Technical Specifications
SIMATIC NET PROFIBUS, Optical Link Module
Operating Instructions, 07/2008, A2B00065774O, Edition V1.5
19
Characteristics Device type
Voltage interruption
Voltage dips
EN61000-4-11,
voltage reduction by >95% for 5 s
voltage reduction by 30% for 10 ms
voltage reduction by 60% for 100 ms and 1000 ms
Climatic ambient conditions
Ambient temperature during operation -25 °C..+60 °C for OLMG12-EEC
0 °C..+60 °C for all other OLMs
Storage and transport temperature -40 °C..+70 °C
Relative humidity 100%, condensing for OLMG1x-EEC
<95%, non condensing for all other OLMs
Mechanical ambient conditions
Oscillation in operation 10..58 Hz, 0.075 mm deflection
58..150 Hz, 1 g acceleration
Oscillation during transportation 5 Hz..9 Hz, 3.5 mm deflection
9 Hz..500 Hz, 1 g acceleration
Vibration in operation 40 m/s²
Shock in operation 150 m/s², 10 ms
Shock packed 250 m/s², 6 ms
Free fall unpacked 10 cm
Free fall packed
30 cm in product packaging
1 m in shipping packaging
Miscellaneous information
Degree of protection IP40
Dimensions 39.5 x 110 x 72.2 mm
Housing material stainless steel, 1.4016
Weight approx. 320 g
Silicone the device is free of silicone
MTBF at 40 °C
76405 h 89831 h 80115 h
MTBF at 85 °C
59442 h 67326 h 61717 h
Table 4-1 Overview of the product characteristics
