optiPoint signature module
34
optiPoint signature module
Safety notes
The optiPoint telephones and add-on devices comply with the stipulated confor-
mity and safety regulations (CE).
• Avoid exposing the equipment to direct sunlight or other sources of heat.
• Protect the equipment from moisture and liquids.
• Never insert objects other than the chip card into openings in the equipment.
Applications
The optiPoint signature module can be connected to the following telephones:
optiPoint 600 office, optiPoint 500 advance/standard/basic,
optiPoint 420 advance/standard, optiPoint 410 advance/standard,
optiPoint 400 standard.
The optiPoint signature module is a chipcard reader which simplifies the use of
PIN-protected functions.
Package Contents
• 1 optiPoint signature module
• 1 connecting cable
Installation
For installation, see fold-out page 3 (Pos.  to ).
1. Disconnect the subscriber line from the optiPoint telephone.
2. Place the telephone  on a soft surface with the keypad facing down.
3. Mount the optiPoint signature module  by snapping it into the slots  on
the telephone or on the installed optiPoint key module.
4. Connect the optiPoint signature module and the optiPoint telephone or the
key module with the supplied connecting cable .
5. Reconnect the subscriber line to the optiPoint telephone.
The optiPoint telephone and the optiPoint signature module are ready for opera-
tion.
The optiPoint signature module can only be operated on the HiPath 4000
communication platform.
