optiPoint Phone Adapter
40
optiPoint Phone Adapter
Safety Notes
The optiPoint telephones and adapters comply with the stipulated conformity
and safety regulations (CE).
• Avoid exposing the equipment to direct sunlight or other sources of heat.
• Protect the equipment from moisture and liquids.
• Never insert objects into openings in the equipment.
Applications
The phone adapter can be connected to the following telephones:
optiPoint 600 office, optiPoint 500 advance/standard/basic.
The phone adapter enables you to connect a second optiPoint telephone without
having to use a special cable.
The port is located on the back of the adapter.
Only one phone adapter can be used with each U
P0/E
subscriber line
Package Contents
optiPoint phone adapter
Installation
For installation, see fold-out page 3 (Pos. to ).
1. Disconnect the subscriber line from the optiPoint telephone.
2. Place the telephone on a soft surface with the keypad facing down.
3. Hold the adapter with the male connectors facing down and insert it into
one of the two adapter bays on the bottom of the telephone by sliding the
two tabs into the two slots .
4. Gently press down on the adapter until the male and female connectors
are completely joined .
5. You can now connect a second optiPoint telephone (any type) to the 6-pin
jack on the back of the phone adapter.
6. Reconnect the subscriber line to the optiPoint telephone.
The optiPoint telephone and the adapter are ready for operation.
