Siemens optiPoint key module User Manual

optiPoint Conference Kit
53
DeutschEnglishFrançaisNederlandsItalianoEspañolPortuguês
Scope of supply for the Order Items
optiPoint Conference Kit Basic (L30250-F600-A605)
For connection to the optiPoint acoustic adapter for 1 conference loudspeaker
unit/ max. 4 conference microphones:
optiPoint Conference Kit Extension (L30250-F600-A606)
For extension to 1 conference loudspeaker unit and max. 4 conference micro-
phones:
For each extension of the optiPoint Conference Kit or extension with 4 micro-
phones, also available are:
Scope of supply Order number
1 conference loudspeaker unit manganese, with connection cable 2 m DUD:VL001
2 conference microphones manganese, with connection cable 0.8 m DUD:VD001
1 power supply unit 230V AC, 24V + 5V DC for max. 2 loudspeakers/
8 microphones
DUD:VN001
1 distribution frame module with
– 1 input for power supply unit
– 1 output to optiPoint conference kit extension
– max. 4 outputs to conference microphone
– 1 output to conference loudspeaker unit
DUD:VM001
1 connection cable power supply unit - optiPoint acoustic adapter 2.5 m DUD:VK008-2.5
1 connection cable power supply unit - distribution frame module 5 m DUD:VK008-5
1 set assembly materials
– 4 connection cables distribution frame module - conference mi-
crophone 4 m
– 2 extension cables to conference microphone 2 m
– 6 coupling bushings for microphone with respective cable exten-
sion
DUD:VZ001
Scope of supply Order number
1 conference loudspeaker unit manganese, with connection cable 2 m DUD:VL001
2 conference microphones manganese, with connection cable 0.8 m DUD:VD001
1 distribution frame module with
– 1 input for basic distribution frame module
– max. 4 outputs to conference microphones
– 1 output to conference loudspeaker unit
DUD:VM001
1 connection cable distribution frame module - distribution frame mod-
ule 5 m
DUD:VK008-5
1 set assembly materials
– 4 connection cables distribution frame module - conference mi-
crophone 4 m
– 2 extension cables to conference microphone 2 m
– 6 coupling bushings for microphone with respective cable exten-
sion
DUD:VZ001
