Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 | Toll Free: 1 • 866 • 396 • 2356 | www.dynafl o.com
P-PS2Q0619A
11
NEW LINEAR MOUNTING INSTRUCTIONS
Figure 4D Feedback Arm Installation Diagram
11
8
ALIGN THE FLAT
OF THE SHAFT
WITH A SET
SCREW HOLE
12
