Hardware Features
36-Point Compact Series Product Diagram
19 |
100
Technical Reference Manual
145-172
Restricted
2018-09-25
Hardware Features
CAUTION
Adjacent point connections on the PXC Compact Series share a Common
connection. See the Figure,
Common and Sensor Power Connections
.
NOTE:
The common for input and output analog points is floating and is not connected to the
common of the 24 Vac input.
Figure 1: Compact 16/24 Shared Ground Connections.
