Points (Command and Release) Application Menu
Menu Overview
● Show Point List screen with correct title bar and filter – host field panel’s onboard
points only
● Point Command screen
● Release Point Priority screen for APOGEE
● Release Point Priority screen for BACnet
● Choose Action for selected point
Menu
Step
Description
Points
Rotate
DIAL
to navigate the list of all local
points.
Press
DIAL
/
OK
to go to the Point Action
screen.
Press
INFO
to view detailed properties of the
selected point.
Title displays “Points” menu.
Displays list of points.
Points Rotate
DIAL
to change point value.
Press
DIAL
/
OK
to apply change and return to
previous screen.
Press
ESC
to return to previous screen
without changing value.
Title displays point name of the point being
commanded. If it can’t be displayed in full, it is
truncated.
Current value is displayed.
Value to be edited is also displayed.
For enumerated point types, the DIAL allows you to
choose a new state.
OK accepts the chosen value.
ESC discards the changes and moves you to point list
screen.
For analog point types, enter the value using the same
method as manual login. See Login Application Menu
[➙ 79].
For BACnet you can choose the associated priority.
Point Action Rotate
DIAL
to select actions.
Press
DIAL
/
OK
to go to the desired screen.
Press
ESC
to return to previous screen.
Title displays “Point Action” submenu.
Line 1 displays Command Point.
Line 2 displays Release Point Priority.
Release Point
Priority for BACnet
Rotate
DIAL
to change point priority.
Press
DIAL
/
OK
to apply change and return to
previous screen.
Press
ESC
to return to previous screen
without changing priority.
The title is the point name of the point being
commanded. If it can’t be displayed in full, it is
truncated.
Enumerated priority values are presented.
DIAL changes enumerated values.
OK releases the selected priority.
Release Point
Priority for APOGEE
Rotate
DIAL
to change point priority.
Press
DIAL
/
OK
to apply change and return to
previous screen.
Press
ESC
to return to previous screen
without changing priority.
The title is the point name of the point being
commanded. If it can’t be displayed in full, it is
truncated.
DIAL changes enumerated values.
OK releases the selected priority.
