If a time scheduler is available, e.g. from the central control unit, Auto Timer mode
is active. The thermostat automatically changes between Comfort and Economy
mode according to the time scheduler using the bus.
The display shows the Auto Timer mode icon .
Touch the operating mode icon to change to another operating mode.
When you are in the Auto Timer mode, and you change the operating mode, the
icon (manual override) displays in place of the icon, indicating that a schedule
being overridden.
Default fan speed in Auto Timer mode is automatic.
Each time the time scheduler sends a new operating mode (switching event), the
thermostat’s operating mode is set back to Auto Timer. This ensures that the room
temperature is maintained according to the time schedule.
If the time scheduler sends the Precomfort mode, it will be switched to Economy
(factory setting) or Comfort (selectable via P88).
If Protection mode is set by the time scheduler, no intervention is possible neither
by users, window contact or presence detector. The screen displays OFF.
You can still access the INFO page.
Touch the operating mode icon to select the operating mode using +/–.
The behavior of the operating mode icon (user profile) can be defined using P02,
factory setting is P02 = 1 (auto-protection).
P02 Without time
schedule
r
With time scheduler
using
bus
Description
1
à à
Auto Timer mode =
Comfort
· Select Comfort or Protection mode when there is
no time schedule from the bus.
· Economy mode is not available
· If the time schedule from the bus is Protection
mode, the operating mode cannot be changed.
· Suited for hotel guest rooms and commercial
buildings.
2
à à à à
If Auto Timer mode =
Comfort
à
If Auto Timer mode =
Economy
· Select Comfort, Economy or Protection mode
when there is no time schedule from the bus
· Economy mode is available
· If the time schedule from the bus is Protection
mode, the operating mode cannot be changed.
· If the time schedule from the bus is Comfort mode,
you can select Economy or Protection mode.
· If time schedule from bus is Economy and P68 is
greater than 0, Comfort mode can be temporarily
extended.
The thermostat can be forced into Protection mode when the window is opened.
The contact can be connected to a multifunctional input X1, X2. Set P38 or P40 to
3. User operations are ineffective and OFF is displayed if the window contact is
active.
Auto Timer mode
with time scheduler
using
the
bus
Note:
Behavior when bus
sends new operating
mode
Precomfort using the
bus
Behavior when bus
sends Protection
Note:
Availability of Economy
mode
Window
contact
