54 / 94
Siemens RDF800KN.., RDF800KN/VB, RDD810KN/NF Basic documentation CE1P3174en
Smart Infrastructure 2020-02-21
· For a detailed description of KNX (topology, bus supply, function and setting of
LTE zones, filter tables, etc.), see "Communication using the KNX bus for
Synco 700, 900 and RXB/RXL, Basic Documentation" [6].
· LTE mode data points and settings are described in the Synco Application
Manual [12].
· To engineer and commission a specific system, use the Synco700 planning and
commissioning protocol (XLS table in HIT, [7]).
3.11.3 Zone addressing in LTE mode (in conjunction with
Synco)
In cases where RDF800KN../RDF800KN/VB/RDD810KN.. KNX room thermostats
are used in LTE mode (e.g. in conjunction with Synco), zone addresses need to be
allocated.
Depending on the application, the following zone address must be defined together
with the Synco devices at the planning stage.
Geographical zone (apartment) --- (out of service) P82
Geographical zone (room) 1 P83
Heat distr zone heating coil 1 P84
Refr distr zone cooling coil 1 P85
· The "Subzone" of the "Geographical zone" is fixed to 1 (not adjustable).
· The device will send and receive LTE communication signals only if the zone
address is valid (not OSV = out of service).
Engineering and
