Siemens RDF800KN.., RDF800KN/VB, RDD810KN/NF Basic documentation CE1P3174en
Smart Infrastructure 2020-02-21
Operational data Switching differential, adjustable
Heating mode (P30)
Cooling mode (P31 for RDF800KN..,
RDF800KN/VB, RDD810KN only)
2 K (0.5...6 K)
1 K (0.5...6 K)
Setpoint setting and range
Comfort (P08)
Economy (P11-P12 for RDF800KN..,
RDF800KN/VB,RDD810KN)
(P11 for RDD810KN/NF)
Protection (P65-P66)
21 °C (5...40 °C)
15 °C/30°C (OFF, 5...40 °C)
15 °C/30°C (OFF, 5...40 °C)
8 °C/OFF (OFF, 5...40 °C)
Multifunctional input X1/X2 for RDF800KN..,
RDF800KN/VB, RDD810KN
Multifunctional input X1/X2 for RDD810KN/NF
Input X1 default value (P38)
Input X2 default value (P40)
Selectable 0...8, 10
Selectable 0, 1, 3, 6, 7, 8, 10
3 (window contact)
1 (external temperature
sensor)
Built-in room temperature sensor
Measuring range
Accuracy at 25 °C
Temperature calibration range
0…49 °C
< ± 0.5 K
± 3.0 K
Settings and display resolution
Setpoints
Current temperature value displayed
0.5 °C
0.5 °C
Environmental
conditions
Operation
Climatic conditions
Temperature
Humidity
As per IEC 60721-3-3
Class 3K5
0...50 °C
<95 % r.h.
Transport
Climatic conditions
Temperature
Humidity
Mechanical conditions
As per IEC 60721-3-2
Class 2K3
-25...65 °C
<95 % r.h.
Class 2M2
Storage
Climatic conditions
Temperature
Humidity
As per IEC 60721-3-1
Class 1K3
-25...65 °C
<95 % r.h.
Standards and
directives
EU Conformity (CE) 8000078258_xx
*)
Electronic control type 2.B (micro-disconnection on
operation)
RCM conformity to EMC emission standard
AS/NZS 61000-6-3
Safety class II as per EN 60730
Pollution class Normal
Degree of protection of housing IP 30 as per EN 60529
Housing flammability class according to UL94 V-0
Environmental
compatibility
The product environmental declaration CB1E3174xx contains data on
environmentally compatible product design and assessments (RoHS compliance,
materials composition, packaging, environmental benefit, disposal).
General Connection terminals Solid wires or prepared
stranded wires
1 x 0.4…1.5 mm
2
or
2 x for KNX cables/sensor
Wiring cross section on
L, N, Q1, Q2, Q3, Y1, Y2
Min 1.5 mm
2
