Siemens RUGGEDCOM RMC20 Installation Guide

RUGGEDCOM RMC20
Installation Guide
Chapter 4
Technical Specifications
Power Supply Specifications 19
Technical Specifications
This section provides important technical specifications related to the device and available modules.
CONTENTS
• Section4.1, “Power Supply Specifications”
• Section4.2, “Fiber Optic Port Specifications”
• Section4.3, “Operating Environment”
• Section4.4, “Mechanical Specifications”
Section4.1
Power Supply Specifications
Power Supply Type Minimum Input Maximum Input Internal Fuse Rating
a
Max. Power
Consumption
24 VDC 18 VDC 36 VDC
48 VDC 36 VDC 59 VDC
88 VDC 300 VDC
HI
b
85 VAC 264 VAC
3.15A (T) 3 W
a
(T) denotes time-delay fuse.
b
This is the same power supply for both AC and DC.
Section4.2
Fiber Optic Port Specifications
The following details the specifications for fiber optic ports that can be ordered with the RUGGEDCOM RMC20.
NOTE
• All optical power numbers are listed as dBm averages. To convert from average to peak add 3 dBm.
To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality, and the number
of patches and splices. Consult a Siemens Sales associate when determining maximum segment
distances.
