Siemens RUGGEDCOM RMC20 Installation Guide

Chapter 4
Technical Specifications
RUGGEDCOM RMC20
Installation Guide
20 Operating Environment
Mode
Connector
Type
Cable
Type (μm)
Tx λ (nm)
c
Tx (dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
c
Power
Budget (dB)
50/125
MM ST
62.5/125
820 -13 -33.5 -11 5 17.5
c
Typical.
Section4.3
Operating Environment
Parameter Range Comments
Ambient Operating Temperature -40 to 85 °C
(-40 to 185 °F)
Measured from a 30 cm (12 in) radius surrounding the center of the
enclosure.
Ambient Relative Humidity 5% to 95% Non-condensing
Ambient Storage Temperature -40 to 85 °C
(-40 to 185 °F)
Section4.4
Mechanical Specifications
Dimensions Refer to Chapter5, Dimension Drawings
Weight 0.68 kg (1.5 lbs)
Ingress Protection IP40 (1 mm or 0.04 in objects)
Enclosure 21 AWG Galvanized Steel
