Siemens RUGGEDCOM RMC20 - Communication Ports; 3.1 Fiber Optic Ports

Communication Ports
3
The RUGGEDCOM RMC20 can be equipped with various types of communication
ports to enhance its abilities and performance.
2
1
1
Port 1
2
Port 2
Figure3.1 Port Assignment
Port Type
1 RS232/RS485/RS422 Serial Terminal
2 Multi-Mode Fiber Optic Port
3.1 Fiber Optic Ports
Fiber optic ports are available with ST (Straight Tip) connectors. Make sure the
Transmit (Tx) and Receive (Rx) connections of each port are properly connected and
matched to establish a proper link.
