Certification
5.2EMC and Environmental Type Tests
5.2 EMC and Environmental Type Tests
The RUGGEDCOM RMC20 has passed the following EMC and environmental tests.
IEC 61850-3 Type Tests
Test Description Test Levels Severity
Levels
Enclosure
Contact
± 8 kV 4IEC
61000-4-2
ESD
Enclosure Air ± 15 kV 4
IEC
61000-4-3
Radiated RFI Enclosure
Ports
20 V/m Note
a
Signal Ports ± 4 kV @ 2.5 kHz Note
a
DC Power
Ports
± 4 kV 4
AC Power
Ports
± 4 kV 4
IEC
61000-4-4
Burst (Fast Transient)
Earth
Ground Ports
± 4 kV 4
Signal Ports ± 4 kV Line-to-Earth,
± 2 kV Line-to-Line
4
DC Power
Ports
± 2 kV Line-to-Earth,
± 1 kV Line-to-Line
3
IEC
61000-4-5
Surge
AC Power
Ports
± 4 kV Line-to-Earth,
± 2 kV Line-to-Line
4
Signal Ports 10 V 3
DC Power
Ports
10 V 3
AC Power
Ports
10 V 3
IEC
61000-4-6
Induced (Conducted) RFI
Earth
Ground Ports
10 V 3
40 A/m continuous,
1000 A/m for 1 s
Note
a
IEC
61000-4-8
Magnetic Field Enclosure
Ports
1000 A/m for 1 s 5
DC Power
Ports
30% for 0.1 s, 60% for
0.1 s, 100% for 0.05 s
IEC
61000-4-29
30% for 1 period,
60% for 50 periods

IEC
61000-4-11
Voltage Dips and Interrupts
AC Power
Ports
100% for 5 periods,
100% for 50 periods

Signal Ports 2 kV (Fail-Safe
Relay output)

DC Power
Ports
1.5 kV 
IEC 60255-5 Dielectric Strength
AC Power
Ports
2 kV 
30
RUGGEDCOM RMC20
Installation Manual, 04/2021, C79000-G8976-1007-10
