RUGGEDCOM RS8000T
Installation Guide
Chapter 1
Introduction
Supported Fiber Optic Cables 5
that during a transient electrical event, communications errors or interruptions may occur, but recovery is
automatic.
Siemens also does not recommend using copper Ethernet ports to interface with devices in the field across
distances that could produce high levels of ground potential rise (i.e. greater than 2500 V), during line-to-ground
fault conditions.
CONTENTS
• Section1.5.1, “Supported Fiber Optic Cables”
Section1.5.1
Supported Fiber Optic Cables
The following fiber optic cable types are supported under the stated conditions.
Distance (m)
Cable Type Wavelength (nm)
Modal Bandwidth
(MHz·km)
100Base-FX 1000Base-SX 10GBase-SR
850 200 — 275 33OM1 (62.5/125)
1300 500 2000 — —
850 500 — 550 82OM2 (50/125)
1300 500 2000 — —
850 1500 — 550 300OM3 (50/125)
a
1300 500 2000 — —
850 3500 — 550 400OM4 (50/125)
a
1300 500 2000 — —
a
Laser optimized.
