Chapter 5
Technical Specifications
RUGGEDCOM RS8000T
Installation Guide
20 Failsafe Relay Specifications
Section5.2
Failsafe Relay Specifications
Voltage Current
30 VAC 0.3 A
30 VDC 1 A
80 VDC 0.3 A
Section5.3
Copper Ethernet Port Specifications
The following details the specifications for copper Ethernet ports that can be ordered with the RUGGEDCOM
RS8000T.
Speed
e
10/100Base-TX
Connector RJ45
Duplex
e
FDX/HDX
Cable Type
f
> CAT-5
Wiring Standard
g
TIA/EIA T568A/B
Maximum Distance
h
100 m (328 ft)
Isolation
i
1.5 kV
e
Auto-negotiating.
f
Shielded or unshielded.
g
Auto-crossover and auto-polarity.
h
Typical distance. Dependent on the number of connectors and splices.
i
RMS 1 minute.
Section5.4
Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber optic Ethernet ports that can be ordered with the RUGGEDCOM
RS8000T.
Mode
j
Connector
Type
Cable
Type (μm)
Tx λ (typ.)
(nm)
Tx min.
(dBm)
Tx max.
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
50/125 1310 -16 -11 -33.5 -11 17
MM MTRJ
62.5/125 1300 -19 -14 -31 -14
2
12
SM LC 9/125 1310 -15 -8 -31 -5 15 16.5
j
MM = Multi-Mode, SM = Single-Mode
