Page #18 background imageLoading...
Page #18 background image
Chapter 2
Installing the Device
RUGGEDCOM RS8000T
Installation Guide
8 Mounting the Device
5. Connect the device to the network.
6. Configure the device.
Section2.2
Mounting the Device
The RUGGEDCOM RS8000T is designed for maximum mounting and display flexibility. It can be equipped with
connectors that allow it to be installed in a 48 cm (19 in) rack, 35 mm (1.4 in) DIN rail, or directly on a panel.
IMPORTANT!
Heat generated by the device is channeled outwards from the enclosure. As such, it is recommended
that 2.5 cm (1 in) of space be maintained on all open sides of the device to allow for some
convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a reduction of ambient
temperature and improve the long-term reliability of all equipment mounted in the rack space.
NOTE
For detailed dimensions of the device with either rack, DIN rail or panel hardware installed, refer to
Section5.7, “Dimension Drawings”.
CONTENTS
Section2.2.1, “Mounting the Device on a DIN Rail”
Section2.2.2, “Mounting the Device to a Rack”
Section2.2.3, “Mounting the Device to a Panel”
Section2.2.1
Mounting the Device on a DIN Rail
To mount the device to a standard 35 mm (1.4 in) DIN rail, do the following:
1. Align the adapters with the DIN rails and slide the device into place.
