RUGGEDCOM RS8000T
Installation Guide
Chapter 5
Technical Specifications
Power Supply Specifications 19
Technical Specifications
This chapter provides important technical specifications related to the device.
CONTENTS
• Section5.1, “Power Supply Specifications”
• Section5.2, “Failsafe Relay Specifications”
• Section5.3, “Copper Ethernet Port Specifications”
• Section5.4, “Fiber Optic Ethernet Port Specifications”
• Section5.5, “Operating Environment”
• Section5.6, “Mechanical Specifications”
• Section5.7, “Dimension Drawings”
Section5.1
Power Supply Specifications
Input Range
Power Supply Type
Minimum Maximum
Internal Fuse Rating
ab
Maximum Power
Consumption
c
12-24 VDC 10 VDC 36 VDC 6.3 A(F)
24 VDC 18 VDC 36 VDC 5 A(F)
48 VDC 36 VDC 59 VDC 3.15 A(T)
HI (125/250 VDC)
d
88 VDC 300 VDC 3.15 A(T)
HI (110/230 VAC)
d
85 VAC 265 VAC 3.15 A(T)
15 W
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than fiber optic ports.
d
This is the same power supply for both AC and DC.
