Siemens RUGGEDCOM RS8000T User Manual

Certification
6.2EMC and Environmental Type Tests
Test Description Test Levels Severity
Levels
AC Power
ports
5 kV 
IEEE 1613 (C37.90.x) EMC Immunity Type Tests
Note
The RUGGEDCOM RS8000T meets Class 2 requirements for an all-fiber configuration
and Class 1 requirements for copper ports.
IEEE Test IEEE 1613
Clause
Description Test Levels
Enclosure Contact ±8 kVC37.90.3 9 ESD
Enclosure Air ±15 kV
C37.90.2 8 Radiated RFI Enclosure ports 35 V/m
Signal ports ±4 kV @ 2.5 kHz
DC Power ports ±4 kV
AC Power ports ±4 kV
Fast
Transient
Earth ground ports ±4 kV
Signal ports 2.5 kV common
mode @ 1MHz
DC Power ports 2.5 kV common and
differential mode @ 1MHz
C37.90.1 7
Oscillatory
AC Power ports 2.5 kV common and
differential mode @ 1MHz
Signal ports 5 kV (Failsafe Relay)
DC Power ports 5 kV
HV Impulse
AC Power ports 5 kV
Signal ports 2 kVAC (Failsafe Relay)
DC Power ports 1.5 kVDC
C37.90 6
Dielectric
Strength
AC Power ports 2 kVAC
Environmental Type Tests
Test Description Test Levels Severity Levels
IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40
°F), 16 Hours

IEC 60068-2-2 Dry Heat Test Bd 85 °C (185
°F), 16 Hours

IEC 60068-2-30 Humidity (Damp
Heat, Cyclic)
Test Db 95% (non-
condensing), 55 °C
(131 °F), 6 cycles

IEC 60255-21-1 Vibration 2 g @ 10-150 Hz Class 2
IEC 60255-21-2 Shock 30 g @ 11 ms Class 2
RUGGEDCOM RS8000T
Installation Manual, 01/2021, C79000-G8976-1023-05
29
