Siemens RUGGEDCOM RSG909R Installation Guide

Chapter 2
Installing the Device
RUGGEDCOM RSG909R
Installation Guide
18 Connecting the Device to the Network
LO Power Supply Configurations
+
-
Figure16:Single Low DC Power Input Configuration
+
-
+
-
Figure17:Dual Low DC Power Input Configuration
Section2.7
Connecting the Device to the Network
Steps to connect the device to the network are application-specific.
Connecting to a Local Area Network
In this application, the device operates as a switch on a Local Area Network (LAN). Connect the device as follows:
