Technical Specifications
5.6Mechanical Specifications
5.6 Mechanical Specifications
Weight 2.4 kg (5.3 lbs)
Ingress Protection IP40
Enclosure Die Cast Aluminum
5.7 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
7
9
10
8
90
176.52
162.72
Figure5.1 Overall Dimensions
28
RUGGEDCOM RSG910C
Installation Manual, 02/2020, C79000-G8976-1405-06

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens RUGGEDCOM RSG910C and is the answer not in the manual?

Siemens RUGGEDCOM RSG910C Specifications

General IconGeneral
Product TypeEthernet Switch
Switching Capacity20 Gbps
Forwarding Rate14.88 Mpps
Ports8x 10/100/1000Base-T(X), 2x 100/1000Base-X SFP
Operating Temperature-40°C to +85°C
RedundancyYes
Mounting TypeDIN Rail
Protocol SupportIEEE 802.1Q
EnclosureMetal
CertificationsIEC 61850-3, IEEE 1613, UL 60950-1
