47/69
Siemens Building Technologies Electronic Air / Fuel Ratio Control System CC1P7873.1en
HVAC Products 15 Programming the RVW26... 15.10.2002
Functions
4SetPts : 9
9Disturb: 15
Aux 2 Di s : o f f
Hyst er : 0. 20
Parameter Meaning
SetPts
Number of breakpoints per curve
Settings: 5 / 9 / 17
Factory setting: 9
Parameter «SetPts» is used to select whether 5, 9 or 17 breakpoints shall be pro-
grammed.
«SetLoad» (programming level 5) is then used to approach the individual curve-
points.
The positions of the auxiliary actuators can now be adjusted for every curvepoint.
If the RVW26... is switched from programming mode to operating mode, pa-
rameter «SetPts» automatically changes to 9.
Each time a curvepoint is changed with setting 5 or 9, the intermediate values will
be calculated by the RVW26...
Disturb
Impact of the correcting variable (refe to chapter «Application of a correcting vari-
able»)
Setting range: 0...50 %
Increment: 1
Factory setting: 0
Aux2Dis
Impact of correcting variable on auxiliary actuator 2
Parameter «Aux2Dis» must be set to «on» only if the auxiliay actuator acts on the
main airflow.
This is the case with an additional air damper or an adjustable head.
The impact on the auxiliary actuator poosition is that described in chapter «Appli-
cation of a correcting variable».
Settings: on / off
Factory setting: off
Hyster
Extent of compensation of hysteresis
Setting range: 0.00...0.50 V
Increment: 0.1 V
Factory setting: 0
Programming level 4
Display
Interpretation
