Siemens RWF55.51A9 User Manual

87/93
Building Technologies Division User Manual RWF55... CC1U7867en
Infrastructure & Cities Sector 15 Key 05.11.2013
15 Key
A Switch-on point for high-fire when response threshold (q) is reached
ACrA
Response by Out of Range
Adr
Device address Modbus
AF
Alarm function
AL
Limit value
At1
Outside temperature 1
At2
Outside temperature 2
B Switch-off point for burner
bdrt
Baudrate
bin1
Binary input 1
bin2
Binary input 2
binF
Binary input
CACt
Operating action
Cntr
Controller
CodE
Level lockout
ConF
Configuration
CtYP
Controller type
db
Dead band
dECP
Decimal point
dF1
Filter time constant
dF2
Filter time constant
dF3
Filter time constant
dFt
Data format
diSL
Lower display
diSP
Display
diSU
Upper display
dSP
Setpoint
dt
Derivative action time
dtt
Remote Detection Timer
End
End value
FnC2
Function
FnC3
Function
FnCt
Function
Ht1
Boiler temperature 1
Ht2
Boiler temperature 2
HYS1
Switch-on threshold heating controller
HYS2
Switch-off threshold heating controller
HYS3
Switch-off threshold heating controller
HYS4
Switch-on threshold cooling controller
HYS5
Switch-off threshold cooling controller
HYS6
Switch-off threshold cooling controller
HYSt
Switching difference
InP
Analog input
InP1
Analog input 1
(actual value)
InP2
Analog input 2 (external setpoint or setpoint shifting)
InP3
Analog input 3 (outside temperature)
IntF
Interface
OFF1
Correction of measured value
OFF2
Correction of measured value
OFF3
Correction of measured value
oLHi
Upper working range limit
oLLo
Lower working range limit
OPnt
Zero point
OPr
User
OutP
Control outputs
