VPN tunnel between SCALANCE M-800 and S612
3.3 Secure VPN tunnel with certificates
SCALANCE M-800 Getting Started
122 Getting Started, 06/2015, C79000-G8976-C337-04
The configuration file contains the exported configuration information for the SCALANCE M-
800 including information on the additionally generated certificates.
Configuration file
Settings in WBM
IPsec VPN > Certificates
Upload Remote Site Certificate: Configuration-
1.group1.S612.cer
Upload PKCS12 File (.p12): Configuration-
1.U800CB3FF@G471C.M-800.p12
System > Load&Save > HTTP > IPSecCert : Load
IPsec VPN > Connections > VPN Standard Mode -
Edit Settings
Security > IPSec VPN > Remote End > Remote Mode: Standard
Address of the remote site's VPN gateway:
91.19.6.84
Security > IPSec VPN > Remote End > Remote Address:
91.19.6.84/32
Authentication method: X.509 remote certificate Security > IPSec VPN > Authentication > Authentication: Remote
Cert
Remote Certificate: Configuration-1.group1.S612.cer Security > IPSec VPN > Authentication > Remote Certificate: Con-
figuration-1.Gruppe1.CP.cer
Remote ID: U5A634732@GC4D8 Security > IPSec VPN > Authentication > Remote ID:
U5A634732@GC4D8
Remote net address: 192.168.184.0
Security > IPSec VPN > Remote End > Remote Subnet:
192.168.184.0/24
Remote subnet mask: 255.255.255.0
Local net address: 192.168.100.0
Security > IPSec VPN > Connections > Local Subnet:
192.168.100.0/24
Local subnet mask: 255.255.255.0
IPsec VPN > Connections > Edit IKE
Security > IPSec VPN > Connections > Keying Protocol: IKEv1
Phase 1 - ISAKMP SA
--
ISAKMP-SA encryption: 3DES-168
Security > IPSec VPN > Phase 1 > Encryption: 3DES
ISAKMP-SA hash: SHA-1
Security > IPSec VPN > Phase 1 > Authentication: SHA-1
ISAKMP-SA mode: Main mode --
ISAKMP-SA lifetime (seconds): 86400
The value is specified in seconds in the text file. In
the WBM, the value must be entered in minutes.
Security > IPSec VPN > Phase 1 > Liftime [min]: 1440
Phase 2 - IPSec SA
--
IPsec SA encryption: 3DES-168
Security > IPSec VPN > Phase 2 > Encryption: 3DES
IPsec SA hash: SHA-1
Security > IPSec VPN > Phase 2 > Authentication: SHA-1
IPsec SA lifetime (seconds): 86400
The value is specified in seconds in the text file. In
the WBM, the value must be entered in minutes.
Security > IPSec VPN > Phase 1 > Liftime [min]: 1440
Perfect Forward Secrecy (PFS): No
--
DH/PFS group: DH-2 1024 Security > IPSec VPN > Phase 1 > Key Derivation: DH group 2
Security > IPSec VPN > Phase 2 > Key Derivation: DH group 2
NAT-T: On
--
DPD delay (seconds): 150 --
