Connecting SCALANCE M-800 to WAN
1.3 Connecting M826 with SHDSL
SCALANCE M-800 Getting Started
Getting Started, 06/2015, C79000-G8976-C337-04
63
Station 1 and 2 - connection to SCALANCE M826
● In the test setup, in the station, a network node is implemented by an Admin PC
connected to an Ethernet interface of the M826.
– Admin PC: represents a node of the station
● Connection to the private network:
– Cable connection via the SHDSL interface of the M826 on company owned 2-wire
cable.
Required devices/components
Use the following components for setup:
● Connection to SHDSL
– 3 x M876 (additional option: a suitably installed standard rail with fittings)
– 3 x 24 V power supply with cable connector and terminal block plug
● 3 x PC each connected to an M826.
● PST is installed on the PC.
Settings used
For the configuration example, the devices are given the following IP address settings:
Interface
IP address
Master
station
M826 SHDSL
(external)
Vlan 2 192.168.184.2
255.255.255.0
Ethernet
(internal)
Vlan 1 192.168.100.1
255.255.255.0
Admin PC Ethernet
(internal)
192.168.100.20
255.255.255.0
Station 1 M826 SHDSL
(external)
Vlan 2 192.168.184.22
255.255.255.0
Ethernet
(internal)
Vlan 1 192.168.11.2
255.255.255.0
Admin PC Ethernet
(internal)
192.168.11.40
255.255.255.0
Station 2 M826 SHDSL
(external)
Vlan 2 192.168.184.42
255.255.255.0
Ethernet
(internal)
Vlan 1 192.168.50.2
255.255.255.0
Admin PC Ethernet
(internal)
192.168.50.40
255.255.255.0
