Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
177
Description
●
Tag Information Forwarding
In the management program that evaluates the AeroScout frames, you can specify
whether or not a SCALANCE W700 device will forward frames. Here, you can see which
setting was made in the management program.
Note
With a suitable configuration, the SCALANCE W700 forwards AeroScout frames but does
not process or evaluate them itself. This is done only in the "AeroScout System Manager"
program.
●
AeroScout status
Shows whether AeroScout is enabled or disabled.
●
Engine port
The SCALANCE W700 device expects UDP packets from the management program at
port 1144.
●
Response IP
The IP address of the computer on which the management program for evaluation of the
AeroScout frames is running.
●
Multicast address
The tag sends frames as multicast. This multicast address is configured in the
management program and displayed here.
●
Sent confirmations
The number of confirmations sent by the SCALANCE W700 device to the management
program as a result of cyclic queries or manual configuration changes in the management
program (UDP packets).
●
Discarded messages
The number of frames not forwarded. If, for example, an AeroScout tag is configured so
that it sends on channel 1, the SCALANCE W700 device does not forward a frame
received on channel 6.
6.4.16.4
iPRP
On this WBM page you can check whether the settings for iPRP are correct. You can, for
example, see which device is the partner client.
Note
This WBM page can only be configured with the following KEY
-PLUGs:
•
Access point: W780 iFeatures (MLFB 6GK5 907-8PA00)
•
Client: W740 iFeatures (MLFB 6GK5 907-4PA00)
