Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
295
The "Default Values" button sets the selection of values to conform with the standard.
Procedure
To configure a certain data transmission speed on WLAN 1:
1. Enable the "Use selected data rates only'" option for "WLAN 1".
2. From the "Radio" drop-down list, select the entry "WLAN 1".
3. Select the appropriate check box in the "Enabled" column and in the "Basic" column for
the required data transmission speed.
4. Click the "Set Values" button.
:
1. Click the "Default Values" button. The selection is reset to the default setting.
AP 802.11n data rates
Data transmission speeds in IEEE 802.11n
Note
This WBM page is only available in access point mode.
The WBM page can only be configured if "802.11n only" or 802.11n is set for WLAN
mode.
The WBM page shows the available data transmission speeds (MCS = Modulation and
Coding Schemes) for the WLAN mode 802.11n. You can select any combination of these
data transmission speeds. The access point will then use only the selected data
transmission speeds for communication with the clients.
