Technical basics
4.1 Configuration limits for WBM and CLI
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
48 Configuration Manual, 08/2018, C79000-G8976-C267-13
Configurable function
Maximum number
Security
IP addresses from RADIUS servers
• AAA: 4
• WLAN: 2
Management ACLs (access rules for management)
10
MAC ACL rule configuration
20
Ingress and egress rules for MAC ACL (total) 40 per interface (20 ingress rules /
20 egress rules)
• Client: 80 (P1, WLAN)
• Access point: 680 (P1, WDS
1,Y, VAP 1,Y)
• Dual access point: 1320 (P1,
WDS X,Y, VAP X,Y)
IP ACL rule configuration
20
Ingress and egress rules for port ACL IP (total) 40 per interface (20 ingress rules /
20 egress rules)
• Client: 120 (P1, WLAN, man-
agement VLAN)
• Access point: 720 (P1, WDS
1,Y, VAP 1,Y, management
VLAN)
• Dual access point: 1360 (P1,
WDS X,Y, VAP X,Y, manage-
ment VLAN)
User roles
28
User groups
32
Users
28
