Assembling

4.8 Wall mounting

SCALANCE X-300

Compact Operating Instructions, 05/2016, A5E00982643-14

4.8

Wall mounting

1. For wall mounting, use suitable mounting fittings for the wall

(for example, for a concrete wall, four plugs 6 mm diameter and 30 mm long, 4 screws

3.5 mm diameter and 40 mm long).

2. Connect the electrical cable connecting cables.

3. Fit the connectors for the signaling contact.

4. Insert the terminal blocks into the sockets on the IE Switch X-300.

Note

For more exact dimensions, please refer to the section "Dimension drawings".

Note

The wall mounting must be capable of supporting at

least four times the weight of the

Switch X-300.

Note

For wall mounting of a rack device (R), use suitable fittings and mount the device as

shown in the drawing.
