Siemens Servo Ventilator 300 - Connector and Block Diagrams

7
120 Siemens-Elema AB E382 E380E 061 01 03 01
Index Servo Ventilator 300/300A
Introduction Description of functions Disassembling and assembling Service procedures Product change history
Functions Included in PC board
Pressure amplifier (Insp. valve) Inspiratory valve unit – Air PC 1601 – 64 – – –
Pressure calculator Inspiratory valve unit – Air PC 1601 – 64 – – –
Pressure PID control Reference & Timing PC 1605 – 60 – – –
Pressure transducer (Exp.) Expiratory pressure PC 1611 – 71 – – –
Pressure transducer (Insp.) Inspiratory pressure PC 1611 – 70 – – –
R
Reference & Timing – PC 1605 10 49 90 – 114
Respiratory pattern Front panel – – 26 – – –
S
Safety valve driver Inspiratory channel PC 1613 – 69 – – –
Safety valve Inspiratory channel – 11 69 – – –
Serial communication ports Computer interface PC 1587 – 32 – – –
Sound & Alarm control Monitoring PC 1608 – 45 – – –
Supply pressure amplifier Inspiratory valve unit – Air PC 1602 – 64 – – –
Supply pressure transducer Inspiratory valve unit – Air – – 63 – – –
T
Transducer temperature control Expiratory flow linearization PC 1615 – 75 – – –
Transformer Mains power – 11 76 95 – –
V
Valve code transponder Inspiratory valve unit – Air PC 1600 – 63 – – –
Valve control – PC 1622 11 73 – – –
Valve enabling Valve control PC 1622 – 73 – – –
Valve position calculator Inspiratory valve unit – Air PC 1603 – 65 – – –
Valve zeroing Valve control PC 1622 – 73 – – –
Version labels – – – 24 – – –
Voltage control & Timing Power supply PC 1618 – 78 – – –
Voltage distribution Power supply PC 1618 – 78 – – –
Voltage setting – – – – – 105 –
Volume Front panel – – 26 – – –
Z
Zero offset (Exp.) Expiratory flow linearization PC 1615 – 75 – – –
Zero offset (Insp.) Inspiratory valve unit – Air PC 1602 – 64 – – –
